Preparation for Using your new TV
Caution: Do not plug the TV in until you have finished connecting all of your equipment.
Connecting your TV
To enjoy its multimedia features, you can connect your
to A/V equipments such as VCR, DVD, STB, Satellite
receiver, Camcorder, Audio amplifier etc., and select signal sources using your remote control.
TV
Connect the
devices
as shown below.
Connecting to A/V equipments
- 5-
1
Notes: Modes that YP
B
P
R
/YC
B
C
R
can display include:480P/60Hz,480I/60Hz,576P/50Hz,576I/50Hz
720P/50Hz,720P/60Hz,1080I/50Hz,1080I/60Hz
You can use your TV as a monitor/speakers for
connecting through its 15pin standard RGB
interface
and PC audio interface.
your computer by
Connect the devices as shown below.
Connecting to a Computer
