FRONT PANEL JACKS AND CONNECTIONS
FRONT PANEL JACKS AND CONNECTIONS
• The front panel jacks are provided as a convenience to allow you to easily connect a
camcorder or VCR as shown in the following examples.
Front panel connections illustration
NOTE:
• Completely insert the connection cord plugs when connecting to front panel jacks. If you
do not, the played back picture may be abnormal.
• If you have an S-VHS VCR, use the S INPUT cable in place of the standard video cable.
