Hayter Mowers RANGER 53 PRO 396E - Manual (Page 2)

Main Features
1.2
MAIN FEATURES /SPECIFICATIONS
1
2
3
4
5
6
7
9
10
11
12
13 14
15
16
17
18
8
1. Spark Plug Lead.
2. Primer Bulb.
3. Engine Cover.
4. Air Filter.
5. Fuel Filler Cap.
6. Oil Filler Cap & Dipstick.
7. Height of Cut Lever.
8. Serial No. Label.
9. Rear Deflector.
10. Handlebar Securing Knob
11. Engine Start Grip.
12. Throttle Control.
13. Lever - Engine Stop.
14. Handlebar.
15. Ground Drive Clutch Lever.
16. Ground Drive Speed Control.
17. Grassbag Assembly.
18. Muffler Guard.
Briggs & Stratton Intek Edge 60
121602-0315-E1
2900 rpm
Unleaded petrol.
1.5 litres
SAE 30 engine oil
0.6 litres
530mm
25 - 85mm
1705 x 585 x 1025mm
60.5 Kg
NGK BCP5RES/CHAMPION RC12Y2
0.50mm
Engine
Engine type
Engine / cutterblade speed
Fuel type
Fuel capacity
Oil type
Oil sump capacity
Cutting width
Cutting height
Overall dimensions
Dry Weight
Spark Plug
Spark Plug Gap
CODE 396
(SG56 RC VAR PRO)
MODELS
Specifications
