Philips HQ 6990 - Manual (Page 12)

5 Clean the cutter with the short-bristled side of
the cleaning brush.
Brush carefully in the direction of the arrow.
6 Brush the guard.
7 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit, push it down (1) and turn the
wheel clockwise ().
8 Put the shaving unit back onto the shaver.
extra through cleaning
For extra thorough cleaning, put the shaving heads
in a degreasing liquid (e.g. alcohol) every six months.
To remove the shaving heads, follow steps 1 to 4
described above. After cleaning, lubricate the central
point on the inside of the guards with a drop of
sewing machine oil to prevent wear of the shaving
heads.
trimmer (all types except HQ6920)
Clean the trimmer every time you have used it.
1 Switch off the shaver. Remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
1
2
1
2
EnglisH 1
