II. GENERAL INFORMATION

1. CONSTRUCTION

[a] KM-630MAF

Water Supply
Inlet

Junction Box

Condenser

Fan Motor

Strainer

Compressor

Drier

Spray Tubes

Control Box

Control Switch

Bin Control

Expansion
Valve

Float Switch

Water Pump
