6
Title: A. Ice Dispenser Assembly Model: DCM-750BAH-OS, DCM-750BWH-OS
Index
No. Description
Material or Model
Number
Part Number
Required Number
N-0
to
P-1 P-2
Q-0
to
U-0
U-1
to
V-0
V-1
to
A-1
Ice Dispenser Assembly
Order Assembly
Parts Individually
DCM-750BAH-OS 1A0747A01 1 -
1A0747A03 1 1 -
1A0747A05 1 -
1A2001A02 1
DCM-750BWH-OS 1A0747A02 1 -
1A0747A04 1 1 -
1A0747A06 1 -
1A2002A02 1
1 Socket Head Cap Screw
(fasteners for Ice Making
Unit) 8×110, SS 7S12-0811 3 3 3 3 3
2 Split Lock Washer (fasteners
for Ice Making Unit) 8, SS 7L22-0800 3 3 3 3 3
3 Thumbscrew (fasteners for
Dispensing Motor) 415949G11 3 3 3 3 3
4 Thumbscrew (fasteners for
Agitating Motor (L)) 415949G11 4 4 4 4 4
5 Thumbscrew (fasteners for
Agitating Motor (R)) 415949G11 4 4 4 4 4
6 Evaporator Bracket 431738-01 1 1 1 1 1
6a Hex Head Bolt w/Washer (Lf) 5×12, SS 7B0230512 2 2 2 2 2
7 Spout 103932G01 1 1 1 1 1
7a Thumbscrew 415949G11 3 3 3 3 3
8 Spout Packing (A) 427195-01 1 1 1 1 1
9 Spout (B) 208807-01 1 1 1 1 1
9a Thumbscrew 415949G11 4 4 4 4 4
10 Spout Packing (B) 427196-01 1 1 1 1 1
11 Gasket 429758-01 3 3 3 3 3
12 Bin Cover 228433A01 1 1 1 1 1
12a Thumbscrew 415949G12 4 4 4 4 4
13 Collar 4H0171-01 2 2 2 2 2
14 Dispensing Auger 339194G01 1 1 1 1 1
15 Agitator (Right) 321013G01 1 1 1 1 1
16 Agitator (Left) 319017G02 1 1 1 1 1
17 Cup Guide 326702-01 2 2 2 2 2
18 Panel (Lower) 228436G01 1 1 1 1 1
19 Drip Tray 2A2591G02 1 1 1 1 1
20 Rear Panel DCM-750BAH-OS 228437-01 1 1 1 1 1
DCM-750BWH-OS 228440-01 1 1 1 1 1
21 Side Panel (Left) DCM-750BAH-OS 2A2637-01 1 1 1 1 1
DCM-750BWH-OS 2A2675-01 1 1 1 1 1
22 Side Panel (Right) DCM-750BAH-OS 2A2638-01 1 1 1 1 1
DCM-750BWH-OS 2A2676-01 1 1 1 1 1
23 Top Panel 3A2526G01 1 1 1 1 1
24 Apron Panel 3A2529G01 1 1 -
3A3615G01 1 1 1
25 Water Sensor Assembly 4A2849G02 1 1 -
4A3753G02 1 1 1
