Hunter Fan 42711-01 User Manual
Page 13
13
inSTalling ThE ThErMoSTaT
inSTalling ThE Wall plaTE
1. Remove the wall plate from the new
thermostat by pressing the release tab on the
bottom of the thermostat.
2. Position the new wall plate on the wall and
pull the labeled wires through the opening.
3. If the existing holes do not match those
on the Hunter wall plate, or if there are no
existing holes, visually level the wall plate
and mark the wall for two holes.
