Hayter Mowers Hovertrim 185E XR16 - Manual (Page 24)

1.24
Item No. Description Part No. Qty Item Note
1 ALLEN XR44 DECAL 111-1516 1
2 ALLEN XR16 DECAL ONLY 111-1825 1
3 WASHER 1/4*7/8*.08" THK 09263 2
4 NUT M6 NYLOC 'T' TYPE 09438 3
5 CABLE TIE HY3966 3 NOT SHOWN
6 BOLT M6*45 09568 1
7 SCREW PLASTITE DIA 5*22 PAN POZI 09765 3
8 SCREW SOC HD BUTTON M6*16 09784 4
9 DECAL - SAFETY PETROL 111-0083 1
10 OPC WIRE LOOM ASSEMBLY 111-2054 1
11 LOGO ALLEN H295128 1
12 BOLT M6X55 HEXBZP-TUF H292309 2
13 ENGINE - HONDA GXV57 111-1245 1
14 BELL MOUTH 111-1299 1
15 ENGINE PLATE 111-1300 1
16 IMPELLER - MOULDED ASSEMBLY 111-1302 1
17 GRIP - HANDLE BAR H292276 2
18 HANDLE - LOWER H292254 1
19 SUMP COVER 111-1303 1
20 CUTTING DISC 111-1381 1
21 ENGINE MTG SCREW M6X20 SFS 111-1500 4
22 SCREW M5*45 PPD 111-1501 8
23 NYLOC NUT M5 FLANGED 111-1502 8
24 5X5X20 SQUARE ENDED DRIVE KEY 111-1503 1
25 BOLT UNF 2,1/4" X 1/4 HEX HEAD 111-1504 1
26 SPRING DISC 40mmOD 1/4"ID 111-1515 1
27 M6 U BOLT BZP H292026 2
28 BAIL ARM H290239 1
29 SWITCH BOX RH 111-1525 1
30 UPPER HANDLE H290237 1
31 RETURN SPRING 111-1773 1
32 P-CLIP 15.8*4.6 NATURAL 111-1792 1
33 FLEXIBLADE LINE - 143MTRS 111-1797 1
34 SWITCH BOX LH 111-1816 1
35 WASHER M6 (SCHIEBEE) 100.000.630 2 NOT SHOWN
36 R CLIP H192040 3
37 RETAINING PIN H192169 3
38 FOOTSTOP H192181 1
39 HANDWHEEL M6 FEMALE IN H192204 2
40 DECK 16" H192257 1
41 STOP DECAL H295159 1
42 HI RISE KIT HI-RISE KIT 16" 1 NOT SHOWN
43 FASTENER DRIVE 6.5 341033 2 NOT SHOWN
44 GUIDE CABLE HY412008 2 NOT SHOWN
45 DECAL - MAN EYE / EAR PROTECTION 111-2153 1 NOT SHOWN
MAINFRAME PARTS LIST
111-1519 (A) 28/1/08 4:44 pm Page 1.24
