Attach wheel carriage assembly to base (1) with bolt (13), washer (22), and nut (7)
as shown. FINGER TIGHTEN - NO TOOLS REQUIRED. Assembly will be fully
tightened in next step.
3.
4.
9
2
3
10
THE SPACER (10) WILL
FIT LOOSELY UNTIL
SECURED INTO THE
CAVITY OF THE BASE.
IMPORTANT!:
BE SURE THAT THE
SQUARE PORTION OF THE
CARRIAGE BOLT (13) IS
PROPERLY SEATED IN
THE SQUARE CUT-OUT OF
THE WHEEL BRACKET.
IMPORTANT!:
1
13
7
22
Install wheel axle (2) through wheel bracket (9) and install wheels (3) onto wheel
axle (2) with spacers (10) as shown.
