Part No 350324 Form No F090407A 15
PR & OS Owner’s Manual
PARTS BAG SEEDER BOX KIT 350326
15 8024021 BOLT CARRIAGE 1/4-20 X 3/4" 2
17 8160001 NUT LOCK 1/4 2
19 8160002 NUT LOCK 5/16 (REQUIRE ON THE OLD MODELS ONLY) 4
20 8177011 WASHER LOCK 5/16 4
23 8041026 SCREWCAP 5/16-18 x 3/4 4
27 8172020 WASHER 5/16 FENDER 4
28 8172007 WASHER 1/4 SAE 2
31 8171006 WASHER 1/2 FC 3
32 8161044 NUT LOCK 1/2" THIN HGT 1
- 350327 LIT SEEDER BOX (INCLUDES TEMPLATE) 1
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 350366 BOX AND LID ASSEMBLY 1
2 350306 BRACKET ADJ DROP SEEDER ASSY 1
3 350276 BAR DOOR LINKGAGE 1
4 350320 SHAFT PLASTIC DROOP SEEDER 1
5 350271 PLATE DOOR DROP SEEDER 1
6 350272 PLATE DOOR DROP SEEDER END 1
7 350273 PLATE DOOR DROP SEEDER ARM 1
9 350370 PULLEY 3V GROOVE 0.625" BORE 1
10 8171003 WASHER 5/16 FLAT CUT 1
11 900321 BEARING CLIP 1.375 OD 4
12
13
400217 SPRING TENSION 2
14 8024040 BOLT CARRAIGE 5/16 - 18 X 1 1
15 8024021 BOLT CARRIAGE 1/4-20 X 3/4" 1
16 8123087 SCREW SELF TAP #10-24 X 3/8" HMS ZP 4
17 8160001 NUT LOCK 1/4 2
18 350332 BRACKET SLOT PLASTIC SEEDER BOX 1
19 8160002 NUT LOCK 5/16 1
21 350369 PULLEY 3V GROOVE 1.530" BORE 1
22 8172013 WASHER FLAT 5/8 SAE ZP 2
24 350372 BELT O-RING 5/16 X 15 9/16" 1
25 8197031 PIN COTTER 1/8" X 1" 1
26 9195106 ROLL PIN 1/8 - 1 1/4 1
28 8172007 WASHER 1/4 SAE 1
29 8154007 NUT HEX 10-24 2
30 8059136 SCREWCAP #10-24 X 3/4 2
32 350288 LABEL INSTRUCTION SEEDER BOX 1
33 890456 LABEL HOSE PLUG KD/SV 1
32 350313 LABEL PRODUCT DECAL OS 1
POWER RAKE SEEDER BOX KIT P/N 350325
