12
ቩ POWER light indicator
To turn the TV ON, press the main power
switch located on the lower right side of the
TV. A red stand-by indicator lamp located on
the lower right corner of the front bezel will
illuminate. The Plasma TV is now ready for
remote ON/OFF operation.
ቪ REMOTE CONTROL sensor
Point your remote at this area when selecting
channels, adjusting volume, etc.
ቫ Component SIDE INPUT JACKS (for INPUT: 5)
Front/Rear/Side Panel Controls
First time use
Indicating Lamp Power Status Operating
When the main power switch is set to Off. OFF.
When the main power switch on the TV
(Stand-by) is ON.
Blinking
Blue
n O
TV MAIN POWER is ON with no signal input
(Power Saving) except antenna (no sync. signal).
Lamp 1 Lamp 2
Lamp 1 Lamp 2
Off Off
Lights
Red
Off
OFF.
Lights
Blue
Off
Off
(Turning ON )
OFF.
TV MAIN POWER is ON ; but no picture is shown.
TV MAIN POWER is ON ; picture is shown.
Lights
Orange
Off
Off
NOTES: 1. Your HITACHI Plasma TV will appear to be turned OFF (lights orange) if there is no video input
when INPUT : 1, 2, 3, 4 and 5. Check the Power Light to make sure the TV is turned off or
in Stand-by mode (lights red) when not in use.
2. Remote Control can not turn ON/OFF the “MAIN POWER” of the TV.
INPUT 5 provide Y-P B P R jacks for
connecting equipment with this capability, such as
a DVD player or Set Top Box. You may use
composite video signal for this input.
NOTE: 1.
2.
3.
4.
Your component outputs may be labeled
Y, B-Y, and R-Y. In this case, connect the
components B-Y output to the TV’s P
B
input and the components R-Y output to
the TV’s P
R input.
Your component outputs may be labeled
Y-C B C R . In this case, connect the component
C B output to the TV’s P B input and the
component C R output to the TV’s P R input.
It may be necessary to adjust TINT to
obtain optimum picture quality when using
the Y-P
B P R inputs (see page
37).
INPUT 3
, INPUT 4 and INPUT 5 (Y/VIDEO) can
be used for composite video and component
video input.
