SKU 95499
for technical questions, please call 1-800-444-3353.
PRE-StARt INStRuCtIONS – Adding Compressor Oil
IMPORtANt!
1.
Prior to first using the Compressor, the Compressor
MuSt be filled
with a high quality
S.A.E. 15W-30W grade non-detergent compressor oil.
OIL SIGHt GLASS
(21)
OIL bREAtHER CAP
(24)
fIGuRE E
dESIREd LEVEL
2.
To do so, unscrew and remove the Oil Breather Cap (24). Pour approximately 1/2
quart of compressor oil into the Oil Breather Cap hole.
do not overfill.
(See figure E.)
Observe the level of compressor oil through the Oil Sight Glass (21). The optimal
3.
oil level is at the center of the glass.
When finished adding compressor oil, re-install the Oil Breather Cap (24) back into
4.
the Oil Breather Cap hole.
(See figure E.)
