Page 9
7
CONTROLS & FEATURES
COMPONENT & CONTROL LOCATIONS
Use these illustrations to locate and identify the most frequently used
controls.
HANDLEBAR
SHIFT LEVER
THROTTLE LEVER
DISCHARGE GUARD
FUEL TANK CAP
RECOIL
STARTER GRIP
CUTTING HEIGHT
ADJUSTMENT LEVERS
MUFFLER
OIL FILLER CAP
CUTTING HEIGHT
ADJUSTMENT LEVER
GRASS BAG
HANDLEBAR
LOCKING KNOB (2)
ENGINE SERIAL
NUMBER
HRB216 TDA (zone start).book Page 7 Monday, March 26, 2001 1:05 PM
