Controls & features 10 – HONDA HRB216TDA User Manual
Page 12
CONTROLS & FEATURES
10
Flywheel Brake Lever
This lever is connected to the
engine flywheel brake and the
ignition switch. The engine will
not start unless this lever is
pushed forward.
Drive Clutch Lever
The drive clutch lever engages
and disengages the
transmission speed selected
by the shift lever (page 11).
The drive clutch lever operates
like a traditional clutch and
should always be fully engaged
or released in a smooth, even
motion.
The flywheel brake lever must
be engaged before the drive
clutch lever can be used.
FLYWHEEL BRAKE LEVER
DRIVE CLUTCH LEVER
FLYWHEEL BRAKE LEVER
HRB216 TDA (zone start).book Page 10 Monday, March 26, 2001 1:05 PM
