5
1.Lean the machine down gently with the front
surface facing the ground. Loosen the eight
screws by a cross screwdriver.
3. Extend the drain hose from the left side. Push
the drain hose into the groove with hands.
4. Install the bottom plate (as per indicated
before), then lift the machine up gently.
2. Pull out the drain hose from the groove at the
right side.
Back
Front
Bottom plate
Soft item
Use groove at
this side after
direction changing
Page 4
Push the drain hose
into the groove with
hands at this point
How to change the direction of the drain hose
Usage of the drain hose
The drainage shall be smooth with the drain hose
1.P ut the drain hose up to suitable position.
Do not put it on ground.
Notes: the mouth of drain pipe should higher
than the water level of washing tub for
avoiding to siphon phenomenon during
drain.
Do not tramp or press the drain hose.
Mouth of
drain hose
<1.2m
0.7m
