Home Automation 10A11-1 - Manual

Model 10A11-1, Rev C
Two-Way Audio/Voice Alarm Module
Home Automation, Inc. New Orleans, LA • Phone 800-229-7256 • Fax 504-736-9290
DESCRIPTION
The Model 10A11-1, Rev C Two-Way Audio/Voice Alarm Module allows two-way communication with a central station after an
alarm, paging and listening from an on-premises or remote phone, annunciation of alarm and zone by voice, and voice messaging.
The Model 10A11-1, Rev C also provides a line-level audio output that can be tied into an amplifier or whole home audio system, and
a page output that is activated whenever the Model 10A11-1, Rev C generates audio output.
FEATURES
• Two independent audio amplifiers
• Two microphone inputs
• Line-level audio output (3.5mm jack)
• Page output (contact closure)
• Automatic gain control (AGC) for talk and listen
• Two-way or listen-only operation
• Control via standard Touch-Tone phone
• Connects to HAI Speaker/Microphone Modules and/or Omni Consoles and Lumina Keypads with Built-in Speaker/Microphone
• Connects to Hi-Fi by HAI and other whole home audio distribution systems for announcing voice messages and paging
INSTALLATION
Connect 8-ohm speaker(s) and two-wire electret microphone(s) to the Model 10A11-1, Rev C - See Figure 1. HAI Model 28A00-1
(Surface) or Model 28A00-2 (Flush) Speaker/Microphone Modules and/or Model 33A00-4 Omni Consoles and Model 33A00-20
Lumina Keypads with Built-in Speaker/Microphone can be used.
NOTE: Do not mount speakers, microphones, 28A00 modules, 33A00-4 consoles, or 33A00-20 keypads near any device that may
produce noise (fans, air conditioning units, audio speakers, etc.).
Microphones:
Microphones should be connected with 24 AWG or larger, shielded twisted pair wire. Wire length should not exceed 100 feet.
Connect the cable shields and negative wires together at the Model 10A11-1, Rev C terminal block only.
Do not connect the shield on the microphone end. Additional microphones can be connected to each input in parallel.
Speakers:
Speakers should be connected with 18 AWG or larger, twisted pair wire. For wire runs that exceed 50 feet, use 16 AWG wire or
larger. Wire length should not exceed 100 feet. Additional speakers can be connected to each output in series.
Line-Level Audio Output:
A power amplifier may be connected to the line-level audio output using a 3.5mm patch cable. This is typically used to annunciate the
audio output from the Model 10A11-1, Rev C throughout a home when used with a whole home audio distribution system.
Page Output:
The page output provides a contact closure whenever the Model 10A11-1, Rev C generates audio. This is typically used to trigger the
paging feature of a whole home audio distribution system.
