Husqvarna 288XP - Manual (Page 34)

34
– English
288XP/XP Lite
5,3/87
2,1/54
1,5/38
2 500
4,5/ 9 600
SEM
AM 7
Champion RCJ 6Y
0,020/0,5
Tillotson
HS 283A
1,9/0,9
9-12-15-18
1,1/0,5
Automatic
XP: 16,5 /7,5
XP Lite: 16,1 /7,3
15-32"/38-80
13-31"/34-79
21,4
3/8
0,058/1,5
7
Engine
Cylinder volume, cu.in/cm 3
Cylinder bore, inch/mm
Stroke, inch/mm
Idle speed, rpm
Power, kW/ rpm
Ignition system
Manufacture
Type of ignition system
Spark plug
Electrode gap, inch/mm
Fuel and lubrication
system
Manufacturer
Carburetor type
Fuel capacity, US pint/litre
Oil pump capacity at 8500 rpm,
ml/min
Oil capacity, US pint/litre
Type of oil pump
Weight
Without bar and chain, Lbs/kg
Chain/bar
Recommended bar lengths,
inches/cm
Usable cutting length,
inches/cm
Chain speed at max.
power, m/sec
Pitch, inches
Thickness of drive link, inch/mm
Number of teeth on drive
sprocket
TECHNICAL DATA
Recommended original and replacement bar
and chain combinations
The Husqvarna chain saw models 288XP and 288XP Lite
are in the ANSI category of saws above 3,8 cu. in. and are
not
required to comply with low kickback performance
requirements. For these Husqvarna models we recommend
the following cutting equipment.
288XP Lite
Guide bar Saw chain
Length Pitch Max nose
inch inch radius
15-32 3/8 11T Husqvarna H42 / S48 / H41 or
Oregon 73VL / 73LG / 73LP
288XP
Guide bar Saw chain
Length Pitch Max nose
inch inch radius
15-32 3/8 11T Husqvarna H42 / S48 / H41 or
Oregon 73VL / 73LG / 73LP
The combinations of power head, bar and chain have been
investigated in accordance with the vibration requirements
of ANSI B 175.1-1991.
Note: For the chains above you are free to choose
between 0,050" and 0,058" gauge drive link for the
corresponding bar, see the table below.
0,058"/1,5mm H42 S48 H41 73VL 73LG 73LP
0,050"/1,3mm – – – 72VL 72LG 72LP
WARNING! These chain saw models are capable
of severe kickback that could result in serious
injuries to the user. Do not operate these saws
unless you have extraordinary cutting needs and
experience and specialized training for dealing
with kickback. Saws with significantly reduced
kickback potential are available. Always use the
safest saw and cutting equipment applicable to
your cutting need.
!
