15
Installing Duct Installation
NOTE: Cold return water temperature (Sustained temperatures below 140 degrees Fahrenheit) will lead to condensation in the
firebox. This moisture can lead to creosote formation. To help minimize moisture and creosote, it is strongly recommended that
some form of temperature balance is incorporated into the return water system.
NOTICE: when installing with the atmospheric conversion: All of the pressurized system components shown are not nec-
essary. Air vents or bleeders will need to be removed from the plumbing system to prevent air from entering the lines. Control
Dipswitch #6 will need to be turned “ON”.
3/4”
3/4”
