WSR 1000 reciprocating saw
7
WSR1000 operating controls
Ẅ
³ Blade clamp / blade holder
ᕢ Stroke rate regulator
ᕣ Switch interlock
ᕤ Control switch
Component parts
Ẅ
ᕥ
Type plate
ᕦ
Motor
ᕧ
Gearing section
ᕨ Front-end grip area
ᕩ
Clamping lever
µ Contact shoe
¸
Saw blade
Description
The WSR1000 is an electrically powered tool for cutting
wood, metal, plastics and composites. It is intended for
professional use.
The following items are supplied: electric tool, operat-
ing instructions, saw blade, toolbox.
The following conditions must always be observed
when the tool is in use:
– The tool must be connected to an alternating current
electric supply in compliance with the information
given on the type plate.
– The tool is for hand-held use only.
– The tool must not be used in places where the sur-
rounding conditions may present a risk of explosion.
General information
In these operating instructions, this symbol indicates
points of particular importance to safety. The instruc-
tions at these points must always be observed in order
to avoid the risk of serious injury.
Caution: high voltage
Ẅ The numbers refer to the illustrations. The illustra-
tions can be found on the fold-out cover pages. Keep
these pages open while you read the operating instruc-
tions.
In these operating instructions, the power tool to which
these operating instructions apply is referred to as “the
tool”.
It is essential that the operating
instructions are read before the
tool is operated for the first time.
Always keep these operating
instructions together with the tool.
Ensure that the operating
instructions are with the tool when
it is given to other persons.
Contents Page
General information 7
Description 7
Technical data 8
Safety precautions 9
Preparation for use 10
Operation 10
Sawing 10
Blades and accessories 11
Care and maintenance 11
Warranty 11
Disposal 12
Troubleshooting 12
Declaration of conformity See cover
