ITEM NO.

49

SHAFT ROLLER WELDED

111-0589

1

1

50

SHROUD-FREEWHEEL

340168

1

1

51

SPRING COUNTER BALANCE

410050

1

1

52

SPRING TORSION HOC

480132

1

1

53

SPRING VARIATOR

HY412004

1

1

54

SPROCKET 10T

411011

1

1

55

SPROCKET 18T

411010

1

1

56

THROWPLATE

111-0218

1

1

57

UNDERDECK CHUTE

111-0131

1

1

58

UNDERDECK COVER

111-0133

1

1

59

PULLEY VARIATOR ASSY

411001

1

1

60

WASHER PLAIN 5/16x1x16G

09270

1

1

61

WASHER PLAIN M5

ZWP1E000U

2

2

62

WASHER SPRING 3/8" SC

09273

1

1

63

WASHER STARLOCK 5/16"

0201086

2

2

64

WHEEL WITH BEARINGS

HY5218

2

2

65

NUT M6 NYLOC

ZNN1J000U

1

1

66

CLUTCH LEVER

411020

1

1

67

SPRING

411021

1

1

68

PULLEY

411019

1

1

69

PIN

411023

1

1

70

BELT VARIATOR 450

411025

1

1

71

CHARGER NOT ILLUSTRATED

412010

0

1

QTY.

490 491

DESCRIPTION

PART NO.

ITEM NOTE

LOWER

MAINFRAME PARTS LIST

1.35
