1 CLIP GRASSBAG FLAP 111-0458 2 2
2 BATTERY 12V HY412009 0 1
3 BATTERY COVER 111-0595 1 1
4 BOLT HANDLEBAR HY226024 2 2
5 CABLE ENGINE BRAKE 111-0700 1 1
6 CABLE GUIDE V/S 410037 4 2
7 CABLE_CLUTCH 111-0701 1 1
8 CAP FOR M8 NUT BLACK HY234051 2 2
9 HANDLEBAR CLAMP PLATE 340028 2 2
10 FLAP_GRASSBAG 111-0196 1 1
11 DEFLECTOR 111-0633 1 1
12 ENGINE XTS50 DUAL A/C B&S 111-0203 1 0
ENGINE XTS50 DUAL A/C E/S B&S 111-0205 0 1
13 ENGINE STOP LEVER 340179 1 1
14 FRAME_GRASSBAG 111-0194-03 1 1
15 GRASSBAG 111-0197 1 1
16 GUIDE_ROPE 305093 1 1
17 HANDLEBAR LOWER 410034W 2 2
18 HANDLEBAR UPPER MOULDED 341029 1 1
19 LEVER CLUTCH 306094W 1 1
20 BOLT COACH M8 x 40 GRADE 8.8 09379 2 2
21 NUT M6 NYLOC ‘T’ TYPE 09438 2 2
22 NUT M8 NYL INSERT T TYPE 09441 2 2
23 PIN PIVOT 340182 2 2
24 RATCHET PLATE HOC 111-0201 1 1
25 FASTENER DRIVE 6.5 341033 1 1
26 ROD DEFLECTOR 560017 1 1
27 SCREW TAPTITE M6*16 09365 4 4
28 FASTENER DRIVE 300144 4 4
29 SCREW TAPTITE UNC 3/8"*1 1/4" 09349 3 3
30 SCREW 06*20 PT PAN FLANGE 09687 2 2
31 SETSCREW M6x55 POSI PAN Z&P 09780 2 2
32 CONTROL THROTTLE 410035 1 1
33 SPRING DEFLECTOR 410030 1 1
34 CABLE VARIATOR 111-0702 1 1
35 KNOB M8 HANDWHEEL 480088 2 2
36 WASHER NYLON 19*11*1.6 09688 2 2
37 SWITCH AND LOOM ASSEMBLY E/S 561003 0 1
38 KEY ELECTRIC START HY6426 0 1
39 P LU G T U BE 7 / 8 *1 6 G 3 0 0 1 6 0 2 2
40 DECAL HAYTER ROYAL WARRANT 410087 1 1
41 DECAL SERIAL NUMBER -------- 1 1
42 DECAL ENGINE HARRIER 48 111-0759 1 1
43 FOAM PAD TOP HY412012 0 2
44 CABLE TIE HY3966 1 1
45 DECAL HEIGHT OF CUT 320006 1 1
46 GRASSBAG ASSEMBLY 111-0764 1 1 INCLUDES 1,10,14,15
47 CABLE GUIDE HY412008 0 2
48 WASHER PLAIN M6*12*1.6 09472 1 1
49 DECAL CAUTION 111-0083 1 1
50 NUT M6 NYLOC P TYPE 09544 1 1
51 GRIP FIX EXT 5/16 04020 2 2
1.32
ITEM NO.
QTY.
490 491 DESCRIPTION PART NO. ITEM NOTE
LIST PARTS MAINFRAME UPPER
