SKU 66514 for technical questions, please call 1-800-444-3353. Page 6
warning! If the supply cord of this appli-
ance is damaged, it must be replaced
only by a qualified service technician.
cleaning the filter Sponge
Wash the Filter Sponge out regu- 1.
larly, especially if the Fountain Pump
power starts to drop.
Unplug the Fountain Pump from the
2.
power source and wear heavy-duty
insulated rubber gloves before putting
your hands into the water.
Press the sides of the Filter Cover
3.
(14) together and pull it off the Main
Housing (4). Pull the Filter Sponge
out of the Plastic Filter (13) and rinse
with cold, clean water. Replace into
the Plastic Filter (13) and reassemble
the Filter Cover (14).
When not using the Fountain Pump,
4.
(as in the Winter months), protect and
preserve the Filter Sponge by keep-
ing it in a glass jar in water stored
near the Fountain Pump for easy
location.
cleaning the impeller
Unscrew the Back Cover (3), (twist it 1.
1/4 turn to left and pull). Remove the
Impeller (11). See figure 3.
note: there is a small metal washer
attached to the rear of the impel-
ler Shaft. Be careful not to lose
it when removing, cleaning, and
replacing the impeller.
Flush with lots of lukewarm, clean
2.
water to remove built up debris. Use
of a small medium stiff toothbrush is
helpful.
figure 3
Metal Washer
Back Cover (3)
Impeller (11)
3. Replace the Impeller (11) as in num-
ber 1 of this section using reverse
procedure. Check for Metal Washer
before replacing the Back Cover (3).
