Title: C. Ice Making Unit Model: DCM-300BAH, DCM-300BAH-OS
Index
No. Description
Material or
Model Number Part Number
Required Number
A-0
Ice Making Unit
Order Assembly Parts Individually
3A6561A01 1
1 Gear Motor (for mounting
hardware, see section "A"
item 1) 2U0147-01 1
2 Auger 361013G01 1
3 Cutter 440905-01 1
4 Evaporator 2A3308G01 1
4a Split Lock Washer M6, SS 7L22-0600 4
4b Socket Head Cap Screw 6×10, SS 7S12-0610 4
5 Extruding Head 327141G01 1
5a Seal Bolt M8 P01768-01 3
5b Washer 453791-01 3
6 Housing 206013G03 1
6a Bolt 6×20, SS 4A1989-01 4
7 Mechanical Seal 432491-01 1
8 Ring 432494-01 1
9 Spline Coupling 418316-01 1
10 "O" Ring 4A4755-01 1
10
