ASSEMBLY INSTRUCTIONS
ASSEMBLING THE MOWER FOR THE FIRST TIME Continued.
Check all fasteners are secure.
Check engine stop lever operation: Operate the engine stop
lever several times. Ensure that the cable moves freely and that
the lever returns automatically to the engine stop position when
released.
CS214
CS232
Check throttle lever operation: Operate the throttle lever
several times and ensure the cable moves freely whilst
operating the engine throttle mechanism.
Check clutch lever operation: Operate the clutch lever
several times and ensure that the cable moves freely.
CS015
CS212
111-0445(A) 21/10/05 10:26 am Page 1.14
