A17

D

A12

A13

A

A

A

Green

Black

White

Bare Copper

Ground

A14

B

D

A16

F

Pull the wires through the strain relief.

Tighten the strain relief screws.

Connect wires as shown.

Connect a 4” duct and vent to the outside. Tape joints.

If ducting does not fit securely, an adapter may need

to be purchased.

Install the wiring cover plate. Make sure all wiring con-

nections are inside the box or under the wiring cover plate.

6

F

A15

B

D
