Page 10

B8
D
Pull the wires through the strain relief and tighten the
strain relief screws.
B9
B
C
D
B10
B11
2
1
B12
D
B13
10
Fit housing into the opening and secure by tightening the
pre-loaded screws into the joist.
Note: Install the box flush with the sheetrock (ceiling).
Insert the strain relief into the housing and secure
with the washer.
Move the housing into position above the ceiling.
Pop out the first wiring access slug. Use second if needed.
41717-01 05/31/2006
41717-01 05/31/2006
Attach existing ducting to duct connector. Tape joints.
If ducting does not fit securely,
an adapter may need to be purchased.
