TRANSDUCER MOUNTING PROCEDURE
Humminbird’s high-speed transducer is supplied with your LCR. This transducer has
been designed to give good high speed readings on most all boat designs, including
aluminum.
Please carefully consider the following before installing your transducer.
TRANSDUCER MOUNTING OPTIONS
A. Transom Mount- The Humminbird high speed transducer allows the transducer
element to be mounted below the bottom of the boat hull keeping the transducer out
of turbulent water and insuring good high speed operation. The transducer will
