18
>SYNC Synchronize the vertical interval sync pulse of your camera with other equipment to
reduce the effect of picture roll on the monitor. Select either:
(default) for cameras using DC power or when line lock is not required,
or
to open the Line Lock screen where you can adjust the Vertical Phase
(V PHASE) from 0 to 624 (519 is the default).
>AGC Automatic Gain Control. This setting affects the day/night threshold. A higher AGC value
results in the camera switching from day to night mode at lower levels. While observing
a video monitor, adjust the noise in the image, from 0 dB to 36 dB.
>WHITE BALANCE Opens the WHITE BALANCE menu where you set how the camera tracks to accept
different lighting conditions within the color range of 2000K to 11000K.
The ATW Normal (default) and ATW Desat (Desaturation) options open the WHITE
BALANCE LIMITS screen where you set the Low and High white balance limits (2100K
to 8800K) while observing the video monitor.
ATW Desat is useful for low light conditions.
Opens the PUSH AWB CONFIRM screen where you save your AWB settings to have
them take effect, or select CANCEL. Auto white balance ensures that color integrity is
maintained.
Caution Selecting Save will overwrite all previous settings.
Opens the MANUAL WHITE BALANCE menu where you adjust the color settings while
observing the scene in the video monitor. Options are:
Move the cursor to set the TINT, from 2K to 11K (2900 is the default).
Adjust the RED and BLUE settings, from -20 to 20. The default red is -18 and
the default blue is 13.
Use this feature when:
•
Non-standard lighting exists or color lighting temperature exceeds the range of the
camera.
• A significant part of the scene contains a single color or a completely red or blue
background.
LINE LOCK
V PHASE
0 519 624
PREVIOUS PAGE .
>
!
WHITE BALANCE LIMITS
LOW LIMIT
2K 2100 5.5K
HIGH LIMIT
5.5K 8800 11K
PREVIOUS PAGE .
>
!
!
>
MANUAL WHITE BALANCE
ADJ MODE
PREVIOUS PAGE .
>
R/B ADJUST
RED -18 -20 20
BLUE 13 -20 20
PREVIOUS PAGE .
!
!
