Home Automation RC-2000 - Manual (Page 16)

1 1 6 6
DISABLE LOCAL CONTROL
The Task Buttons and Scroll Wheel on the thermostat can be disabled to prevent anyone from controlling the
thermostat locally.
To disable the Task Buttons and Scroll Wheel:
1. Remove the thermostat face from the thermostat base.
2.
Remove the local control jumper - See Figure 15.
3. Align the tabs of the thermostat face with the slots of the thermostat base. Gently push the
thermostat face into the thermostat base locking it into place.
TO DISABLE TASK BUTTONS
AND SCROLL WHEEL
REMOVE JUMPER
COMM JUMPER
J8
Figure 15 – Local Control Jumper
