Front Panel Controls
Control Panel Function
1. Standby switch
2.SOURCE Select the input signals: PC/COMPONENT/DVD/HDMI/
TV/SCART/S-VIDEO
3. MENU Press to select the main menu
4. VOL- Volume down / Left orientation to adjust the item in the OSD
VOL+ Volume up / Right orientation to adjust the item/Press to enter
5. CH- TV channel down / to select the item in the menu
CH+ TV channel up / to select the item in the menu
6. Power indicator
Illuminates red in standby mode, illuminates green when the display is
turned on
7.Remote Sensor
6
7
SOURCE MENU VOL- VOL+ CH- CH+ POWER
2 3 4 5 1
SOURCE MENU VOL- VOL+ CH- CH+ STANDBY
(The figure above and the description of the button may be different,
just see the actual set.)
15 inch
Other inch
6
7
12W 11W
