background image

Page 12

For technical questions, please call 1-800-444-3353.

SKU 94487 95553

Air Motor Parts List

Part

Description

Qty

A1 Air Pump Cylinder

1

A2 Nut

1

A3 Sealing Ring

1

A4 Nylon Ring

1

A5 Copper Ring

1

A6 Air Cylinder Seat

1

A7 Nut

1

A8 Spring

1

A9 Air Pump Piston

1

A10 O-Ring

2

A11 Big Piston

1

A12 Air Cylinder

1

A13 Screw

2

A14 Lock Washer

2

A15 Safety Cover

1

A16 Filter

1

A17 Silencing Pad

1

A18 Small Piston

1

A19 O-Ring

1

A20 O-Ring

1

A21 Sealing Ring

1

A22 Bolt

3

A23 Nylon Ring

1

A24 O-Ring

2

A25 O-Ring

1

Part

Description

Qty

A26 Air Cylinder Cap

1

A27 Bolt

3

A28 Coupler Seat

1

A29 Retaining Ring

1

A30 O-Ring

2

A31 Coupler

1

A32 Air Hose

1

A33 Lock Lever

1

A34 Lever

1

A35 Nut

1

A36 O-Ring

1

A37 O-Ring

1

A38 Packing

1

A39 Throttle

1

A40 Spring

1

A41 Lock Nut

1

A42 Bolt

1

A43 Valve Body

1

A44 Inlet

1

A45 Screen

1

A46 O-Ring

1

A47 Quick Coupler, Male

1

A48 Coupler Seat

1

A49 O-Ring (SKU 94487 only)

1
