What’s on the side imaging display – Humminbird 700 series User Manual
Page 20
10
Depth - water depth; can be set to
alarm when the water becomes too
shallow.
Topography Changes
Bottom Return
Speed - if a Speed accessory or GPS
Receiver is attached, the 700 Series™
can display the speed of the boat, and
can keep a triplog of nautical or statute
miles traveled.
What’s on the Side Imaging Display
Side Imaging displays a number of easily recognizable features that allow for accurate inter
composition determines the intensity of the sonar return. For example, rock and gravel provide
Upward slopes that face the transducer reflect sonar better than downward slopes that face
features on the Side Imaging display that allow for accurate interpretation of bottom contour
531519-1_A - 797c2_Man_Eng.qxp 11/6/2006 5:50 AM Page 10
