Hasselblad Flextight 646 - Manual (Page 28)

Technical Specifications
Power Connector:
Power Consumption
Max. 60 W during operation
Power Requirements
100-240V AC, 1.3A, 50-60Hz
Interface to Computer
FireWire (IEEE 1394)
Front Panel
One multifunction switch (on/off switch)
with integrated status light
Drum Force
1kg (2.2lbs)
Operating Environment
Operating Temperature: 10 - 35°C (50 - 95°F)
Recommended Working Temperature: 10 - 25°C (50 - 77°F)
Humidity: 20 - 80% RH (no condensation)
Storage Environment
Temperature: 0 - 50°C (32 - 122°F)
Relative humidity: 20 - 80% RH (no condensation)
Originals
Transparencies: from 35mm to 4x5 inches, <1mm thick
Reflectives: up to 220 x 310mm (A4 oversize), <1mm thick
Lamp type
Color optimized fluorescent lamp
Dimensions
Height: 650 mm (25.6")
Width: 390 mm (15.4")
Depth: 230 mm (9.1") (excl. feed table)
425 mm (16.7") (incl. feed table)
Weight
17 kg (38 lbs)
User's Guide - Flextight 646
Hardware Reference - Flextight 646
28
Technical Specifications
English
24 VDC 60W
