List, Parts – Hayter Mowers Jubilee 424V User Manual
Page 29
NO. DESCRIPTION
PART NO.
QTY
ITEM NOTE
422V
423V
424V
1
Deck - Mainframe 43.
422069
1
0
0
Deck - Mainframe 48.
424031
0
1
1
2
Engine - Quantum 45.
422054
1
1
0
Engine - Quantum 45.
424021
0
0
1
3
Cover - Wheel 200mm.
422046
2
2
2
4
Nut - M8 Binx.
ZNB1H000U
4
4
4
5
Wheel - 200mm.
422044
2
2
0
6
Wheel - 200mm Driven.
424007
0
0
2
7
Washer - Dia. 12.7 Wavy.
422041
4
4
4
8
Washer - M12 L.D. Plain.
ZWP1L000U
8
8
4
9
Stub Axle.
422042
4
4
2
10
Bush - Bearing.
424006
0
0
2
11
Cover - Wheel, Internal.
424005
0
0
2
12
Ratchet - Gear.
424008
0
0
2
13
Pinion - Differential Right.
424010
0
0
1
14
Pinion - Differential Left.
424009
0
0
1
15
Circlip.
09723
0
0
2
16
Nut - M10 Flange.
63-11-015
4
4
4
17
Guard - Belt.
424013
0
0
1
18
Belt - Vee.
424012
0
0
1
19
Gear Box.
424029
0
0
1
20
Connecting Rod - 48.
423010W
0
1
1
Connecting Rod - 43.
422040W
1
0
0
21
Screw - M6 x 16.
09362
3
3
3
22
Nut - M6 Nyloc T Type.
09544
4
4
4
23
Bracket - Rear Axle.
422032
2
2
2
24
Axle - Front W/A.
422062
1
1
1
25
Bracket - Front Axle.
422033
2
2
2
26
Wheel - 180mm.
422043
2
2
2
27
Cover - Wheel 180mm.
422045
2
2
2
28
Spring - Tension.
424014
0
0
1
29
Spring - C/Balance.
422037
1
1
1
30
Bolt - 3/8 UNF x 2"
09121
0
0
1
31
Washer - Plain.
09271
0
0
1
32
Cutterbar 43.
422031
1
0
0
Cutterbar 48.
423004
0
1
1
33
Washer - Belleville
MU17X137
0
0
1
34
Blade Adaptor Pulley.
424003
0
0
1
35
Key - Woodruff.
1662
1
1
1
36
Screw - No8 x 1/2" Plastic Pan Hd 09729
8
8
8
37
Screw - Taptite UNC 3/8" x 11/4". 09349
3
3
3
38
Decal - Hayter & Royal Warrant.
300157
1
1
1
39
Decal - Height of Cut.
320006
1
1
1
40
Lever - Height of Cut.
422036
1
1
1
LIST
1.29
PARTS
