User’s Guide 15
Entering User Modes
The video controller signal may occasionally call for a mode that
is not preset if:
■ You are not using a standard graphics adapter.
■ You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the
monitor screen by using the on-screen display. Your changes can
be made to any or all of these modes and saved in memory. The
monitor automatically stores the new setting, then recognizes the
Factory Preset Display Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 x 350 31.5 70.0
2 720 x 400 31.5 70.0
3 640 x 480 31.5 60.0
4 640 x 480 37.9 72.0
5 640 x 480 37.5 75.0
6 800 x 600 35.2 56.0
7 800 x 600 37.9 60.0
8 800 x 600 46.9 75.0
9 832 x 624 49.7 75.0
10 1024 x 768 48.4 60.0
11 1024 x 768 60.0 75.0
12 1152 x 870 69.0 75.0
13 1280 x 1024 63.9 60.0
14 1280 x 1024 80.0 75.0
15 1600 x 1200 75.0 60.0
