Page 3
3
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
•
WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
•
CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the fireplace or to property.
!
Table of Contents
Congratulations!
2
Warranty
4
1 Listing and Code Approvals
6
A. Appliance Certification
6
B. Non-Combustible Materials
6
C. Combustible Materials
6
User Guide
2 Operating Instructions
7
A. Your Fireplace
7
B. Seasoned Wood
8
C. Starting a Fire
8
D. Grate
8
E. Firescreen
8
F. Flue Damper
8
G. Refractory
8
H. Glass Doors
9
I. Outside Air (optional)
9
J. Vented Gas Log Sets & Gas Log Lighters
9
K. Optional Components
9
L. Clear Space
9
M. Wood Fuel
10
3 Maintenance and Service
11
A. Disposal of Ashes
11
B. Chimney Inspection/Cleaning
11
C. Check Firebox Refractory
12
D. Inspect Grate
12
E. Glass Cleaning
12
4 Troubleshooting Guide
13
Installer Guide
5 Getting Started
14
A. Typical Fireplace System
14
B. Design and Installation Considerations
15
C. Draft
15
D. Negative Pressure
15
E. Locating Fireplace & Chimney
16
F. Tools and Supplies Needed
17
G. Fireplace System Requirements
17
H. Inspect Fireplace and Components
17
6 Framing & Clearances
18
A. Select Fireplace Location
18
B. Clearances
19
C. Sidewalls/Surrounds
20
D. Frame the Fireplace
20
7 Installation of Fireplace
21
A. Things to Consider
21
B. Unpack the Refractory & Fireplace
21
C. Position the Fireplace
22
D. Place Protective Metal Hearth Strips
22
E. Level Fireplace
22
F. Install Refractory
23
G. Install Outside Air Kits
24
8 Chimney Assembly
26
A. Chimney Requirements
27
B. Using Offsets/Returns
28
C. Assemble Chimney Sections
29
D. Install Chimney Air Kit
29
E. Install Ceiling Firestops
30
F. Install Attic Insulation Shield
31
G. Cut out Hole in Roof
32
H. Complete Installation
32
I. Install Flashing
32
J. Chimney Termination Requirements
33
9 Chase Installations
34
A. Construct the Chase
34
B. Install Fireplace & Chimney
35
C. Install Chase Top
35
D. Install Termination Cap
35
10 Shrouds
37
A. Radiation Shield
37
B. Field Constructed Shrouds
37
11 Finishing
39
A. Non-Combustible Materials
39
B. Combustible Materials
39
C. Hearth Extension
39
D. Finishing Material
42
E. Combustible Mantel
43
F. Sidewalls/Surrounds
44
12 Accessories
45
A. Gas Log/Lighter Provision
45
B. Wood Burning Inserts
45
13 Reference Materials
46
A. Fireplace Dimensions
46
B. Optional Components
47
B. Chimney Components
48
D. Service Parts
51
E. Contact Information
52
Heat & Glo • EXCLAIM-50 • 4013-041 • Rev AA • 7/12
