61
Handle Installation
TORQUE:
RIGHT HANDLE
BRACKET
LEFT HANDLE BRACKET
8 16 mm FLANGE BOLT (4)
LEFT UPPER HANDLE ASSY
RIGHT UPPER HANDLE ASSY
Install the right and left handles on the generator upper frame using
the brackets and 6 flange bolts.
17 22 lbf·ft (24 29 N·m , 2.4 3.0 kgf·m)
