ASSEMBLY STEP 3
BOLT (C)
CONSOLE MAST
CONSOLE
CONSOLE WIRES
BOLT (C)
50 mm
Qty: 2
HARDWARE BAG 3 CONTENTS :
ASSEMBLY STEP
HAND RAIL
BASE FRAME
BOLTS (A)
GRIP PULSE
HAND RAILS
BOLT (A)
15 mm
Qty: 4
HARDWARE BAG CONTENTS :
A Open HARDWARE BAG 1.
B Connect CONSOLE WIRES.
C Attach CONSOLE MASTS to BASE
FRAME using 6 BOLTS (A).
D Secure and tighten all bolts.
NOTE: Do not pinch the wires.
ASSEMBLY STEP 1
2.3T – 5.3T ASSEMBLY
A Open HARDWARE BAG 2.
B Place the console upside down on
a padded surface.
C Attach the CONSOLE SKIRT by
partially inserting 2 SCREWS (B)
in the two inner attachment holes.
D Align the CONSOLE SKIRT and
CONSOLE SHELL SEAM. Partially
insert SCREW (B) and repeat for
other side.
E Fully tighten all screws.
ASSEMBLY STEP 2
STEP D: UPSIDE DOWN VIEW OF CONSOLE
BOLTS (A)
CONSOLE MAST
BASE FRAME
CONSOLE WIRES
CONSOLE SKIRT
CONSOLE
SCREWS (B)
CONSOLE SKIRT
SCREWS (B)
CONSOLE SHELL SEAM
BOLT (A)
15 mm
Qty: 6
HARDWARE BAG 1 CONTENTS :
SCREW (B)
12 mm
Qty: 4
HARDWARE BAG 2 CONTENTS :
A Open HARDWARE BAG 3.
B Connect CONSOLE WIRES.
C Attach CONSOLE to CONSOLE
MASTS using 2 BOLTS (C).
D Secure and tighten bolts.
NOTE: Do not pinch the wires.
3.3T & 5.3T models only:
A Open HARDWARE BAG .
B Attach left and right HAND
RAILS to GRIP PULSE HAND
RAILS and BASE FRAME using
4 BOLTS (A).
NOTE: 2.3T models do not
have hand rails and therefore
will NOT include HARDWARE
BAG 4 in the parts box.
