5 01/05 P/N 21165502 P/N 21165502 01/05
Mount extension arm (7) and
rim to backboard using
appropriate instruction sheet.
NOTE: For spring loaded rim
assembly, refer to
instructions included with
rim hardware.
Assemble spider net (13) to all
rims.
Secure extension arm (7) to 3.5”
pole section (8). Install pole cap
(12). Measure rim to be
regulation 10’ from the floor.
Refer To Combo For
Goal Assembly
Instructions
1.
3.
9
10
10
11
7
12
8
Pole Locations
7
2.
