Huffy RC1200 - Manual (Page 4)

P/N 21165502 01/05 4
TWO PEOPLE ARE
NECESSARY TO MOUNT THE
ELEVATOR ASSEMBLY TO
THE POLE. ONE PERSON
SHOULD NOT ATTEMPT TO
DO THIS ALONE.
WARNING
TOP
VIEW
BACK
3-1/2” Rnd. Pole
3-1/2” Rnd. Pole X 30” Pole
Install enclosed pole mounting hardware and pole
for each assembly.
3-1/2” Rnd. Pole
NOTE:
Enclosed Are Two Sets Of
Brackets + Hardware For
(Each) Pole Installation
Upper Support
Railing
3.
3
4
8
6
5
