Circuit diagram
A. Power plug
B. Light switch
C. Sensor 1
D. Sensor 2
E. Sensor 3
F. Sensor 4
G. Sensor 5
H. Air outlet
I. Heater 1
J. Heater 2
K. Fuse
L. Light
M. Freezer fan motor
N. Refrigerator fan motor
O. Overload protector
P. Compressor
Q. PTC
R. Operating capacitor
S. Display screen
T. Power panel
U. Switch 2
HRF-356/396
