Removing and installing the doors – haier PRCS25SD User Manual
Page 6
Removing and Installing the Doors
NOTE
Only required in the event your refrigerator has clearance problems entering your home or getting it
to its operating location.
It is suggested you have 2 or more people present when doing this job in order to complete the job
correctly and avoid personal injury.
Using a Phillips screwdriver remove the
top hinge cover screw and lift off the top
hinge cover.
Then take off the fresh food door
and place it in a safe place.
Removing and Installing the Fresh Food Door
If necessary, remove the middle hinge.
To install the fresh food door, follow
reverse order.
NOTE
When raising the hinge to separate it from the door, be careful not to drop the door.
Perform Step 1 in “Removing and
Installing the Fresh Food Door” above.
Disconnect the wire joint and the water pipe. With a
screwdriver remove the top hinge screw. Remove the
freezer door and place it in a safe place.
Removing and Installing the Freezer Door
