Air Index
Descriptive Term Applicable to Emissions Durability Period
Specifications
GX610 (QAF-Type)
GX620 (QAF-Type)
GX670 (TAF-Type)
17
The durability description is intended to provide you with
information relating to the engine’s emission durability period.
The descriptive term indicates the useful life period for the engine’s
emission control system. See your
Emission Control System
Warranty for additional information.
The bar graph is intended to provide you, our customer, the ability
to compare the emissions performance of available engines. The
lower the Air Index, the less pollution.
388 457 452 mm
(15.3 18.0 17.8 in)
42.1 kg (92.8 lbs)
614 cm (37.5 cu-in)
[77.0 66.0 mm (3.03 2.60 in)]
13.5 kW (18.4 PS, 18.1 bhp) at 3,600 rpm
40.6 N·m (4.14 kgf·m, 29.9 lbf·ft) at
2,500 rpm
1.1 (1.2 US qt , 1.0 Imp qt)
1.4 (1.5 US qt , 1.2 Imp qt)
Forced air
Transistor magneto
Counterclockwise
412 471 457 mm
(16.2 18.5 18.0 in)
43.5 kg (95.9 lbs)
670 cm (40.9 cu-in)
[77.0 72.0 mm (3.03 2.83 in)]
15.3 kW (20.8 PS, 20.5 bhp) at 3,600 rpm
46.0 N·m (4.69 kgf·m, 33.9 lbf·ft) at
2,500 rpm
1.1 (1.2 US qt , 1.0 Imp qt)
1.4 (1.5 US qt , 1.2 Imp qt)
Forced air
Transistor magneto
Counterclockwise
An Air Index Information hang tag/label is applied to engines
certified to an emission durability time period in accordance with
the requirements of the California Air Resources Board.
The power rating of the engine indicated in this document is the
net power output tested on a production engine for the engine
model and measured in accordance with SAE J1349 at 3,600
rpm (Net Power) and at 2,500 rpm (Max. Net Torque). Mass
production engines may vary from this value.
Actual power output for the engine installed in the final machine
will vary depending on numerous factors, including the
operating speed of the engine in application, environmental
conditions, maintenance, and other variables.
Moderate 50 hours [0 80 cm (0 80 cc) inclusive]
125 hours [greater than 80 cm (80 cc)]
Intermediate 125 hours [0 80 cm (0 80 cc) inclusive]
250 hours [greater than 80 cm (80 cc)]
Extended 300 hours [0 80 cm (0 80 cc) inclusive]
500 hours [greater than 80 cm (80 cc)]
The Air Index Information hang tag/label must remain on the
engine until it is sold. Remove the hang tag before operating the
engine.
388 457 452 mm
(15.3 18.0 17.8 in)
42.1 kg (92.8 lbs)
614 cm (37.5 cu-in)
[77.0 66.0 mm (3.03 2.60 in)]
12.4 kW (16.9 PS, 16.6 bhp) at 3,600 rpm
39.6 N·m (4.04 kgf·m) at 2,500 rpm
1.1 (1.2 US qt , 1.0 Imp qt)
1.4 (1.5 US qt , 1.2 Imp qt)
Forced air
Transistor magneto
Counterclockwise
Length Width
Height
Dry mass [weight]
Engine type
Displacement
[Bore
Stroke]
Net power
Max. Net torque
Engine oil capacity
Cooling system
Ignition system
PTO shaft rotation
Length Width
Height
Dry mass [weight]
Engine type
Displacement
[Bore
Stroke]
Net power
Max. Net torque
Engine oil capacity
Cooling system
Ignition system
PTO shaft rotation
Length Width
Height
Dry mass [weight]
Engine type
Displacement
[Bore
Stroke]
Net power
Max. Net torque
Engine oil capacity
Cooling system
Ignition system
PTO shaft rotation
Without oil filter replacement:
approximatly
With oil filter replacement:
approximatly
Without oil filter replacement:
approximatly
With oil filter replacement:
approximatly
Without oil filter replacement:
approximatly
With oil filter replacement:
approximatly
4-stroke, overhead valve, 2 cylinders (90° V-Twin)
4-stroke, overhead valve, 2 cylinders (90° V-Twin)
4-stroke, overhead valve, 2 cylinders (90° V-Twin)
(in accordance with SAE J1349 )
(in accordance with SAE J1349 )
(in accordance with SAE J1349 )
(in accordance with SAE J1349 )
(in accordance with SAE J1349 )
(in accordance with SAE J1349 )
