Model CBC/CBR-103,104,105,106,107
303 2-3
2-4. LOCATION Place the cold bases in an area where product can be loaded and
unloaded without interruption. For proper operation, level the unit
by adjusting the bolts under the base, and leave 3 feet (91.44 cm)
clearance behind the unit for ventilation and service.
For maximum efficiency, units should be operated in an air-condi-
tioned environment, with maximum air temperature of 75° F
(24° C), and 55% relative humidity.
Wait at least 4 hours before plugging the unit into an
electrical supply. The gases and oils in the refrigeration
system need to settle before operating the compressor, or
damage to the compressor could result.
INFORMATION High Low
CBC-103 R22 2.5 lbs (1.134 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-104 R22 2.5 lbs (1.134 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
UL Specs CBC-105 R22 2.5 lbs (1.134 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-106 R22 2.5 lbs (1.134 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-107 R22 2.5 lbs (1.134 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-103 R134A 1.76 lbs (0.800 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-104 R134A 2.20 lbs (1.00 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CE Specs CBC-105 R134A 2.65 lbs (1.200 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-106 R134A 3.09 lbs (1.400 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
CBC-107 R134A 3.53 lbs (1.600 kg) 440psig 162 psig
(30.3 bar) (11.2 bar)
2-6. DRAIN CONNECTION The cold bases-remote (CBR), require 1 inch (25.4 mm) drain
connection. Cold bases with condensing units (CBC) do not
require a plumbed drain.
2-5. REFRIGERATION Refrigerant Type Amount of Refrig. Design Pressure
