42676-01 • 05/13/09 • Hunter Fan Company
Installing the Glass Bowl
7-5. First install B10 candelabra bulbs (60
Watt Maximum) into the
sockets.
7-6. Attach the extra pull chain (included)
to the fan pull chain using the plastic
breakaway connector. (You may find
the plastic breakaway connector on
the end of the extra chain.)
7-7. Thread the fan pull chain through the
hole in the metal disk. Then, thread
the fan pull chain through the hole in
the center of the glass bowl.
7-8. Thread the light pull chain through
the hole in the center of the glass
bowl. Then, Thread the light pull chain
throught the hole in the center of the cover plate.
7-9. Thread the fan pull chain through the grommet hole in the side of
the cover plate.
7-10. Place the cover plate up against the glass bowl. Align the holes in
the cover plate and glass bowl.
7-11. Thread the light pull chain through the finial and screw the finial
onto the threaded rod end until tight.
Light Bulbs
(B10
Candelabra
Base 60 Watt
Maximum)
Metal Rod
Metal Disk
Glass Bowl
Cover Plate
Finial
Note: In compliance with US federal energy regulations, this
ceiling fan contains a device that restricts the light kit to a
maximum of 190 Watts. Exceeding that limit or the marked
limit on this product may result in fire hazard or improper
operation.
12
7 • Completing Your Installation With or Without a Bowl Light Fixture (Continued)
