AXLE ADJUSTMENT
BOLTS
POSITION A
POSITION B
POSITION
C
POSITION
D
PLACE JACK
HERE
Figure 1
REAR AXLE HEIGHT ADJUSTMENT
LOOSEN BOLTS EACH
SIDE
CASTER SWIVEL
1/2" SPACERS
MACHINERY BUSHING
CASTER HEIGHT ADJUSTMENT
Figure 2
Setup & Adjustments
