Valve Assembly Diagram/Parts List
Service Parts
CFX-Crescent
Beginning Manufacturing Date: June 2000
Ending Manufacturing Date: ______
2
3
4
5
1
2
3
6
5
4
Pre 002182991 Valve Assembly Post 002182991 Valve Assembly
ITEM DESCRIPTION
Pre 002182991 Post 002182991
Pilot Assembly NG N/A 385-510A Y
Pilot Assembly LP N/A 385-511A Y
2 Burner Tube 570-302A 570-302A Y
Valve NG 476-500 593-500 Y
Valve LP 476-500 593-501 Y
4 Flex Ball Valve Assembly 492-320A 492-320A Y
5 Module 501-592 593-592 Y
6 Module Wire Assembly N/A 593-590A Y
Ignitor 501-591 N/A Y
3 Volt Transformer N/A 593-593A Y
Stocked
at Depot
1
3
IMPORTANT THIS IS DATED INFORMATION: When Requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
