18
Installation
3.5.4 Protective Cover
Figure 8 Protective Cover
1 Protective Cover 3 Protective Cover with inserted cuvette/sample cell
adapter A in position A.
2 Protective Cover (inside view)
The inside of the Protective Cover is intended to house
the cuvette/sample cell adapters. The recesses for
holding the cuvette/sample cell adapters are marked with
the corresponding letters.
