1

Mainframe - 48

397039V

1

0

Mainframe - 53

399020V

0

1

2

Height Adjust Quadrant

397028

1

1

3

Cover - Black

397037

1

0

Cover - Black

399019

0

1

4

Engine-B+S Quantum XTS 50

397047

1

1

5

Decal - Caution

219189

1

1

6

Key Woodruff

1662

1

1

7

Nut-UNC 1/4” Plain

09197

2

2

8

Knob

397046

2

2

9

Washer 09475

2

2

10

Screw - Plastite

09765

10

11

11

Screw - Taptite

09596

16

18

12

Wheel Assembly

397021

2

0

Wheel Assembly

399009

0

2

13

Handlebar - Lower RH

397004W

1

1

14

Handlebar - Lower LH

307003W

1

1

15

Knob - M8 Handlebar

480088

2

2

16

Guide Rope

305127

1

1

17

Bolt - Handlebar

226024

2

2

18

Plug - Tube

300160

2

2

19

Cable Tie

3966

3

3

20

Nut 09544

1

2

21

Washer - Plain

09472

1

1

22

Guide Rope

305093

1

1

23

Throttle Control & OPC Assemble

397010

1

0

Throttle Control & OPC Assemble

480093

0

1

24

Screw - Detite Posi Pan

09600

2

2

25

Pin Pivot

340182

2

2

26

Lever Engine

340179

1

1

27

Washer - Nylon

09688

2

2

28

Screw - PT Pan Flange

09687

2

2

29

Upper Handlebar

340183W

1

0

Upper Handlebar

399026W

0

1

30

Frame - Grassbag W/A

397005W

1

0

Frame - Grassbag W/A

399005W

0

1

31

Fabric Grassbag

397006

1

0

Fabric Grassbag

399006

0

1

32

Flap - Black

397024

1

1

33

Spring

397025

1

1

34

Flap Attachment - Black

397026

1

1

35

Attachment - RH

397036

1

1

36

Attachment - LH

397035

1

1

37

Battery Holder

397034

1

1

1.32

PARTS LIST

ITEM NO.

QTY.

398C

399C

DESCRIPTION

PART NO.

ITEM NOTE

398016 (0) 10/3/05 11:38 am Page 1.32
