8
Washing sequence
Figure 1
Spin timer
Wash timer
Wash selector
(To set to below 2 minute,
first set to 5 minute then
turn it back. it can increase
the service life of the timer).
(standard current,
strong current)
(to set to below 1 minute,
first set to 2 minute then
turn it back. it can increase
the service life of the timer).
Wash
Figure 3
Figure 2
WASH SELECTOR
1. Fill the water and add the dissolved washing
powder to make the water level reach the preset
position. (Figure 1)
Run washing program for some time to stir and
dissolve the powder completely.
2.Put in the laundries. If the water quantity is
insufficient, please add water.
3.Select the current.
Select the strength of the current according to
the laundries. (Figure 2
4.Select the washing time
Select the washing time according to the
laundries. (Figure 3)
5.After washing, the buzzer will ring. Set the "WASH
SELECTOR" at "DRAIN". (Figure4).
WASH TIMER
Figure 4
Spin water-filling entrance
WASH SELECTOR
SPIN TIMER WASH TIMER WASH SELECTOR
12
9
6
3 15
12
9
6
3 15
Midway spinning
1.
2.
3.
Put the laundries into the spin tub evenly and smoothly.
Spin
Run the foam-removing spinning.
Push
Push
Proper Proper
Outer cover of
the spin tub
Inner cover of
the spin tub
The laundries
are slanting
Gland
No gland
(1) Put the gland in properly.
Please put in the gland properly even if the laundries quantity is small.
(2) Close the inner and outer cover of the spin tub.
(3) Spin for 1-2 minutes.
(1) Open the outer cover of the spin tub.
(2) Insert the water inlet hose into the spin
water-filling entrance on the control panel.
Fill water for about 1 minute.
(3) Close the outer cover of the spin tub.
Spin for 1-2 minutes.
Water inlet hose
Spin water-filling
entrance
9
